EHR SERIES

Introduction

  1. High Temperature Radial Type,105℃, 2000 hours assured Load Life.
  2. Applications: Communications equipment, switching regulators, and industrial applications.

General specifications

  • Capacitance Range _ 0.47uF to 10000uF
  • Rated Working Voltage_6.3Vdc to 450Vdc
  • Load Life _ 2000Hrs @105℃
  • Operating Temp. Range_ V≦100V_-40℃ to +105℃, V≧160V_-25℃ to +105℃
  • Capacitance Tolerance _ ±20%
  • Packaging_ Bulk, Tape/Box, Tape / Reel

Part numbering system

Example

EHR101M25AT1
①~③④~⑥⑧~⑨⑫~⑬

①~③

CODESERIES
EHRWide Temp.

④~⑥

CODECAPACITANCE
0101.0uF
4R74.7 uF
101100uF
1021000uF

CODETOL.
M± 20%

⑧~⑨

CODEW.V.
0J6.3V
1010V
1616V
2525V
3535V
5050V
6363V
2A100V
2C160V
2D200V
2E250V
2V350V
2G400V
2W450V

CODEPACKAGE
AAmmo Pack
BBulk
RTape&Reel

CODESIZE
Omit if only one size
ASmaller Size
SSpecial size

⑫~⑬

CODELEAD SPACE
Omit if Bulk
T1L/S 2.5mm Taped
TALead forming space 5mm Taped
T35L/S 3.5mm Taped
T2L/S 5mm Taped
T3L/S 7.5mm Taped
C5Cut 5mm
F5Lead formed & cut 5mm

Download

Name PDF
EHR SERIES EHR_20190409.pdf
RADIAL TAPING Specification RadialTap_20190620.pdf
